38U Outdoor Enclosure, Aluminum, 4kW Air Conditioner, IP55
The 38U outdoor enclosure, crafted from durable aluminum, offers high strength and robust protection against vandalism and harsh environmental conditions, all while being lightweight. It features two compartments, top 23U space for server or network equipment, while the remaining space is available for batteries, the shelves are included for deploy the batteries convenient.
Product Part Number: 5238020001
- Equipped with 4kW air conditioner, ensuring the adequate climate management inside the enclosure.
- Front and rear door access for easy installation and maintenance.
- Technical Data
- Ordering Information
- Resources
| Material | Two Layers, 3 mm Thickness Aluminum as Outer Layer and 10 mm Thickness Thermal Insulation Foam as Inner Layer. |
| Finish | Pantone 428C Powder Coating finishes |
| Color | RAL7035 Light Grey |
| External Dimension | H2000xW850xD1000 mm, including Plinth H150 mm |
| Protection Level | IP55 |
| Installation | Pad Mount |
| Access | Front Door and Rear Door |
| Loading Capacity | 2000lbs. |
| Rack Mount | 19” |
| Locking Mechanism | 3 Point Locking |
| Cable Access | 12pcs of PG29 Cable Glands at the Bottom |
| Part No. | Description |
| 5238020001 | 38U Outdoor Battery Enclosure, Aluminum, 4kW Air Conditioner, IP55 |
