28U Dual Bay Outdoor Enclosure, Aluminum, 150W Heat Exchanger, IP55
This 28U dual bay outdoor enclosure is designed to protect expensive outdoor equipment or supply power supply in harsh environments, with waterproof and dustproof features. Dual Bay design to provide the adequate space for equipment. Cooling of active equipment is achieved by 150W heat exchanger, along with the vented front door and side door/panel. Various monitoring sensors such as smoke, and access control are installed in the enclosure, allowing personnel to monitor the operation status of the cabinets in real-time.
Product Part Number: 73021000
- Front door and side door access, convenient for installation and maintenance.
- Equipped with door mounted 150W heat exchanger, along with the vented front door and side door/panel, for thermal control
- Technical Data
- Ordering Information
- Resource
| Material | Aluminum, 3.0 mm Thickness |
| Finish | Powder Coating |
| Color | RAL7035 Light Grey |
| External Dimension | H403xW1400x540 mm, without Plinth and Top Cover |
| Protection Rating | IP55 |
| Installation | Pad Mount |
| Access | Front Door and Side Door |
| Maximum Door Opening | 120° |
| Rack Mount | 19” |
| Locking Mechanism | 3 Point Locking |
| Cable Access | 3pcs of PG29 Cable Entries at the Bottom |
| Other Included Parts | 1pc of Ground Bar, 4pcs of L-Rails, 1*16 Pin Terminal Block (UK2.5N) |
| Part No. | Description |
| 73021000 | 28U Dual Bay Outdoor Enclosure, Aluminum, 150W Heat Exchanger, IP55 |
